SF26-AION36X-Boost




120/130/140/150/160




Stanchion: 36
Boost





Our new AION36X is down for anything and can handle it all. Combining many of the features of our race-level forks, the AION36X is the new choice for trail, all-mountain and e-SUB adventures at a budget-friendly price.






  •
                                    specs

    Offset
    44 mm
    Travel
    120/130/140/150/160
    Crown/Steerer
    C68/1.5"to1-1/8" tapered (CTS) Alloy
    Stanchion DIA. (Material)
    36 mm (Alloy)
    Bottom Case Material
    Magnesium
    Brake Mount (Max Rotor DIA.)
    Post 180 Direct (220mm)
    Axle (Option)
    15AH4-110 (Learn more)
    Suggested Category
    eMTB_AM
    ABS Mount
    Yes
    Spring
    AIR(EQ)
    Max. Suggested Tire Size (ETRTO)
    27.5"x2.6" (65-584)
    Damper
    3CR-PCS/2CR-PCS/RC-PCS (Learn more)
    Crown/Steerer (Option-1)
    C74/1.5" straight Alloy
    Axle O.L.D
    ø15-110
    Lamp Mount
    No
    Fender Mount
    Short & Long
    Hub Dynamo Cable Guide
    No


    •

  •
                            technologies

    •





      EQ EQUALIZER™ SYSTEM


      The Air EQ system, perfectly equalizing the rider's weight to the spring curve resulting in exact positioning and support. The Air EQ system creates a customized feel for each rider, optimizing proper sag and volume control in conjunction with the external damping adjustments of our sealed PCS cartridges. The result is a supple coil-spring feel in a lightweight, progressive and easy to adjust air-spring package.


      Learn more




    •





      PCS SYSTEM


      Floating on a magic carpet is the feeling we’re aiming for. Reducing the impact from the ground into your body is the first step. With the PCS as the foundation and completely new designed shim based high-speed compression and rebound circuits, our new R2C2 cartridge is progress in the right direction with our testing data providing proof. Simple, reliable, durable and easy service performance.


      Learn more




    •



  •
                    service





    •

  •
                            models

    AION36X-BOOST EQ ABS 2CR-PCS DS 15AH2-110 27.5"
     AION36X-BOOST EQ 2CR-PCS DS 15AH2-110 27.5"
     AION36X-BOOST EQ ABS RCPCS DS 15AH2-110 27.5"
     AION36X-BOOST EQ RC-PCS DS 15AH2-110 27.5"
    AION36X-BOOST EQ ABS 3CR-PCS DS 15AH2-110 27.5"
     AION36X-BOOST EQ 3CR-PCS DS 15AH2-110 27.5"
     AION36X-BOOST EQ ABS LORC-PCS DS 15AH2-110 27.5"
     AION36X-BOOST EQ LORCPCS DS 15AH2-110 27.5"


    Glossary


















shop now





You are now entering the online shop of SR SUNTOUR North America.










                                            I am aware that extra costs such as shipping, import duties can occur and that delivery times can be longer than mentioned in the terms and conditions of the SR SUNTOUR USA Webshop.




                                    Enter the shop












































































AION36X




A STEP ABOVE





                        Our new AION36X is down for anything and can handle it all. Combining many of the features of our race-level forks, the AION36X is the new choice for trail, all-mountain and e-SUB adventures at a budget-friendly price. With up to 160 mm of travel, 36 mm stanchions, this reinforced, e-bike ready fork is ready to tame the trails without destroying your wallet. Featuring our EQ Air System, PCS Dampers with rebound and compression adjustment, and integrated fenders, you’ll be trail-ready in no time with all the adjustments you need to tailor your ride to your local track. We didn’t forget about those who use their bikes for everything as we’ve included long fender mounts and clearance for 220mm rotors and big tires. The AION36X can really do it all.















Key features










Key features








36mm A7000 triple butted series
Equalizer (EQ) System
3 positions of compression with low speed rebound adjust with PCS

















Magnesium bottom case
15AH4-110, boost standard
Post mount 180 direct

















PCS™ Piston Compensator System
36 mm stanchions from A7000 series alloy
Travel: 120 mm, 130mm, 140mm, 150mm, 160mm





















































































































Technology




  •





    EQ EQUALIZER™ SYSTEM


    The Air EQ system, perfectly equalizing the rider's weight to the spring curve resulting in exact positioning and support. The Air EQ system creates a customized feel for each rider, optimizing proper sag and volume control in conjunction with the external damping adjustments of our sealed PCS cartridges. The result is a supple coil-spring feel in a lightweight, progressive and easy to adjust air-spring package.


    Learn more




  •





    PCS SYSTEM


    Floating on a magic carpet is the feeling we’re aiming for. Reducing the impact from the ground into your body is the first step. With the PCS as the foundation and completely new designed shim based high-speed compression and rebound circuits, our new R2C2 cartridge is progress in the right direction with our testing data providing proof. Simple, reliable, durable and easy service performance.


    Learn more




    •
